Butt Fusion Stub End

Name: Butt Fusion Stub End
Brand: JAIN PIPE TRADERS PRIVATE LIMITED
Price: 300 -1250
Availability: InStock

300 -1250 INR

Get a Price/Quote

Product Details:

Bend Radius Minimum 10 times outer diameter
Temperature Range -40C to 60C
Tensile Strength >23 MPa (at 23C)
Diameter 20 mm to 400 mm
Tolerance 0.5 mm
Connection Type Butt Fusion
Sealing Type No additional seal required (homogeneous welding)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Butt Fusion Stub End Price And Quantity

Price 300 -1250 INR
Minimum Order Quantity 1 Number

Installation Method Butt fusion welding equipment required
Density 0.94 0.96 g/cm
UV Resistance UV Stabilized for outdoor use
Corrosion Resistance 100%
Impact Resistance High
Compliance Conforms to most international standards for HDPE fittings
Hydrostatic Test Pressure 1.5 times rated pressure
Service Life Up to 50 years
Packaging Standard export-worthy packaging or as required
Chemical Resistance Excellent (resistant to a wide range of chemicals)

Butt Fusion Stub End Product Specifications

Usage Pipeline jointing, Water supply, Gas distribution
Thickness 5 mm to 60 mm (varies by size)
Tolerance 0.5 mm
Section Shape Circular
Material Grade PE100, PE80
Rated Pressure PN6, PN10, PN16
Sealing Type No additional seal required (homogeneous welding)
Yield Strength 15-25 MPa (Material dependent)
Length Varies by size (typically 50 mm to 200 mm)
Flexibility Good (Material inherent flexibility)
Product Type Butt Fusion Stub End
Color Black
Material HDPE (High Density Polyethylene)
Connection Type Butt Fusion
Application Water, Gas, Industrial pipeline systems
Outer Diameter 20 mm to 400 mm
Standard DIN 16963, ISO 4427, ASTM D3261, EN 12201
Bend Radius Minimum 10 times outer diameter
Diameter 20 mm to 400 mm
Temperature Range -40C to 60C
Shape Stub End
Tensile Strength >23 MPa (at 23C)
Connection Butt Fusion Welding
Surface Treatment Smooth, Uncoated

Installation Method Butt fusion welding equipment required
Density 0.94 0.96 g/cm
UV Resistance UV Stabilized for outdoor use
Corrosion Resistance 100%
Impact Resistance High
Compliance Conforms to most international standards for HDPE fittings
Hydrostatic Test Pressure 1.5 times rated pressure
Service Life Up to 50 years
Packaging Standard export-worthy packaging or as required
Chemical Resistance Excellent (resistant to a wide range of chemicals)

Butt Fusion Stub End Trade Information

Supply Ability 100 Number Per Day
Delivery Time 1 Days

Product Description

Butt Fusion Stub End

CODE	SIZE	d	D	L	L1
BFSE050050	50mm	50	88	85	12
BFSE063063	63mm	63	102	94	14
BFSE075075	75mm	75	122	105	16.5
BFSE090090	90mm	90	138	117	17
BFSE110110	110mm	110	158	128	18
BFSE125125	125mm	125	158	133	22
BFSE160160	160mm	160	212	176	28
BFSE180180	180mm	180	212	180	32
BFSE200200	200mm	200	268	182	32
BFSE225225	225mm	225	269	180	35
BFSE280280	280mm	280	320	205	35
BFSE315315	315mm	315	374	210	35
BFSE355355	355mm	355	435	225	40
BFSE400400	400mm	400	485	240	45
BFSE450450	450mm	450	530	260	47
BFSE500500	500mm	500	588	280	47
BFSE560560	560mm	560	670	280	51
BFSE630630	630mm	630	690	280	51

Note: All dimension are in mm ( + 2)

Exceptional Durability and Resistance

Designed for longevity, these Butt Fusion Stub Ends offer high impact resistance, excellent chemical compatibility, and total corrosion immunity. The UV-stabilized HDPE construction ensures performance remains uncompromised even under prolonged outdoor exposure, making these fittings ideal for demanding pipeline installations.

Seamless, Leak-Free Connections

Utilizing butt fusion welding, these stub ends create homogeneous, welded joints without the need for extra sealing components. This method delivers robust, reliable, and leak-proof connections that maintain pipeline integrity, minimizing maintenance over their impressive service lifespan.

Versatile Application and Compliance

Conforming to major global standards like DIN 16963, ISO 4427, ASTM D3261, and EN 12201, these stub ends meet rigorous quality and safety requirements. Their adaptability to water, gas, and industrial pipeline systems broadens their usability in varied sectors, while standardized packaging ensures safe transport and delivery.

FAQs of Butt Fusion Stub End:

Q: How is the Butt Fusion Stub End installed in pipeline systems?

A: The Butt Fusion Stub End must be installed using specialized butt fusion welding equipment. This process involves heating both the pipe and stub end, then joining them to create a homogeneous, robust connection without the need for additional sealing materials.

Q: What types of environments can these stub ends be used in?

A: Thanks to their UV-stabilized, corrosion-resistant, and chemically inert properties, these stub ends are suitable for outdoor installations and pipelines exposed to a broad spectrum of chemicals, water, and gases. They are highly effective in both industrial and municipal applications.

Q: When should I choose a Butt Fusion Stub End with high impact and chemical resistance?

A: Select this stub end when your pipeline system demands superior durability against physical impacts, aggressive chemicals, and outdoor conditions. Its robust HDPE construction ensures reliable service even in environments with challenging mechanical or chemical exposure.

Q: Where are these stub ends manufactured and supplied from?

A: These Butt Fusion Stub Ends are available through distributors, suppliers, and traders across India, ensuring wide accessibility for infrastructure and industrial projects nationwide.

Q: What is the benefit of butt fusion welding compared to other joining methods?

A: Butt fusion welding creates a seamless, leak-free connection, resulting in consistent pipeline integrity with minimal pressure loss and zero additional sealing requirements. This reduces long-term maintenance and ensures a service life of up to 50 years.

Q: How does the hydrostatic test pressure relate to product reliability?

A: Each stub end undergoes hydrostatic testing at 1.5 times its rated pressure. This stringent assessment guarantees the fittings reliability and safety under real operating conditions, providing peace of mind for critical water, gas, and industrial systems.
