Male Thread elbow Off- Take

Name: Male Thread elbow Off- Take
Brand: JAIN PIPE TRADERS PRIVATE LIMITED
Price: 59 -370
Availability: InStock

59 -370 INR/Number

Get a Price/Quote

Product Details:

Yield Strength 400 kg/cm2
Tensile Strength 500 kg/cm2
Connection Type Threaded Male
Tolerance 0.1 mm
Flexibility Rigid
Bend Radius 90
Thread Type BSP (British Standard Pipe)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Male Thread elbow Off- Take Price And Quantity

Price 59 -370 INR/Number
Minimum Order Quantity 1 Number

Inner Surface Finish Smooth for Minimal Flow Loss
Leakage Test 100% Leak Tested
Maintenance No Special Maintenance Needed
Packing Type Plastic Bag or Box
Installation Easy to Install, Lightweight
Impact Strength High
Chemical Resistance Excellent against most acids and alkalis
UV Resistance Medium
Lifecycle Over 30 Years
Compatibility Fits with Standard PVC Piping
Fire Resistance Self-Extinguishing
Corrosion Resistance Yes

Male Thread elbow Off- Take Product Specifications

Connection Type Threaded Male
Section Shape Round
Tolerance 0.1 mm
Material Grade UPVC
Color Blue Black
Rated Pressure PN16 (16 Bar)
Material Plastic
Usage For Pipe Connections
Yield Strength 400 kg/cm2
Tensile Strength 500 kg/cm2
Thickness 3 mm
Connection Male Threaded
Application Plumbing, Irrigation, Water Supply
Shape Elbow (90 Degree)
Temperature Range 0C to 60C
Sealing Type Threaded Seal
Diameter 20 mm
Bend Radius 90
Flexibility Rigid
Standard ASTM D2466
Product Type Elbow
Outer Diameter 20 mm
Length 48 mm
Thread Type BSP (British Standard Pipe)
Surface Treatment Smooth, Uncoated

Inner Surface Finish Smooth for Minimal Flow Loss
Leakage Test 100% Leak Tested
Maintenance No Special Maintenance Needed
Packing Type Plastic Bag or Box
Installation Easy to Install, Lightweight
Impact Strength High
Chemical Resistance Excellent against most acids and alkalis
UV Resistance Medium
Lifecycle Over 30 Years
Compatibility Fits with Standard PVC Piping
Fire Resistance Self-Extinguishing
Corrosion Resistance Yes

Male Thread elbow Off- Take Trade Information

Supply Ability 100 Number Per Day
Delivery Time 1 Days
Main Domestic Market Haryana, Delhi, Uttar Pradesh

Product Description

Male Thread elbow Off - Take

CODE	SIZE
CFBM020012	20mm x 1/2"
CFBM020034	20mm x 3/4"
CFBM025012	25mm x 1/2''
CF8M025034	25mm x 1/2"
CF8M025100	25mm x 1"
CFBM032034	32mm x 3/4''
CFBM032100	32mm x 1''
CFBM032114	32mm x 11/4''
CFBM040100	40mm x 1''
CFBM040114	40mm x 1 1/4"
CFBM040112	40mm x1 1/2''
CFBM050114	50mm x 1 1/4"
CFBM050112	50mm x 1 1/2"
CFBM050200	50mm x 2''
CFBM063112	63mm x 1 1/2"
CFBM063200	63mm x 2''
